The Zero Two Series Chassis is available for 4, 8 or 16 Zero Two Modules and one FM002A Facilities Module.
The RK002 may be rack or panel mounted, the latter being supplied with a bezel.
There is a bus on the RK002 which allows all the Zero Two Modules to be connected to the Facilities Module via common bussed features, which are as follows:
- 24 VDC Positive Supply Voltage
- Common System Ground
- A1 Alarm Level 1 Output
- A2 Alarm Level 2 Output
- Fault Malfunction
- Accept Alarm Accept
- UA Alarm Unaccepted / Acknowledged Output
- Reset Master Reset
- Inhibit Alarm Outputs Inhibited
Order Information
| Part Number | Description |
| RK002-02-1-2 | MODEL RK002 02A SERIES RACK / 2 CHANNEL RACK MOUNT W/SCREW TERMINALS / WITHOUT PANEL MOUNT BEZEL / CARDS NOT INSTALLED |
| RK002-02-2-2 | MODEL RK002 02A SERIES RACK / 2 CHANNEL RACK MOUNT W/SCREW TERMINALS / WITH PANEL MOUNT BEZEL (not available with A-02) / CARDS NOT INSTALLED |
| RK002-04-1-2 | MODEL RK002 02A SERIES RACK / 4 CHANNEL RACK MOUNT W/SCREW TERMINALS / WITHOUT PANEL MOUNT BEZEL / CARDS NOT INSTALLED |
| RK002-04-2-2 | MODEL RK002 02A SERIES RACK / 4 CHANNEL RACK MOUNT W/SCREW TERMINALS / WITH PANEL MOUNT BEZEL (not available with A-02) / CARDS NOT INSTALLED |
| RK002-24-1-2 | MODEL RK002 02A SERIES RACK / 4 CHANNEL RACK MOUNT W/O SCREW TERMINALS / WITHOUT PANEL MOUNT BEZEL / CARDS NOT INSTALLED |
| RK002-24-2-2 | MODEL RK002 02A SERIES RACK / 4 CHANNEL RACK MOUNT W/O SCREW TERMINALS / WITH PANEL MOUNT BEZEL (not available with A-02) / CARDS NOT INSTALLED |
| RK002-08-1-2 | MODEL RK002 02A SERIES RACK / 8 CHANNEL RACK MOUNT W/SCREW TERMINALS / WITHOUT PANEL MOUNT BEZEL / CARDS NOT INSTALLED |
| RK002-08-2-2 | MODEL RK002 02A SERIES RACK / 8 CHANNEL RACK MOUNT W/SCREW TERMINALS / WITH PANEL MOUNT BEZEL (not available with A-02) / CARDS NOT INSTALLED |
| RK002-28-1-2 | MODEL RK002 02A SERIES RACK / 8 CHANNEL RACK MOUNT W/O SCREW TERMINALS / WITHOUT PANEL MOUNT BEZEL / CARDS NOT INSTALLED |
| RK002-28-2-2 | MODEL RK002 02A SERIES RACK / 8 CHANNEL RACK MOUNT W/O SCREW TERMINALS / WITH PANEL MOUNT BEZEL (not available with A-02) / CARDS NOT INSTALLED |
| RK002-16-1-2 | MODEL RK002 02A SERIES RACK / 16 CHANNEL RACK MOUNT W/SCREW TERMINALS / WITHOUT PANEL MOUNT BEZEL / CARDS NOT INSTALLED |
| RK002-16-2-2 | MODEL RK002 02A SERIES RACK / 16 CHANNEL RACK MOUNT W/SCREW TERMINALS / WITH PANEL MOUNT BEZEL (not available with A-02) / CARDS NOT INSTALLED |
| RK002-36-1-2 | MODEL RK002 02A SERIES RACK / 16 CHANNEL RACK MOUNT W/O SCREW TERMINALS / WITHOUT PANEL MOUNT BEZEL / CARDS NOT INSTALLED |
| RK002-36-2-2 | MODEL RK002 02A SERIES RACK / 16 CHANNEL RACK MOUNT W/O SCREW TERMINALS / WITH PANEL MOUNT BEZEL (not available with A-02) / CARDS NOT INSTALLED |
